Alpha ProShot Transmitter – Precision for Laser Land Leveling

The Alpha ProShot Transmitter is designed for precise, efficient land leveling. It emits a highly accurate, rotating laser beam, creating a reference point for perfect land grading. By ensuring your land is level, it helps you get the most out of water distribution and boosts crop growth.

Specification :

1. Range with R9 Receiver………………   2000′ dia., 1000′ rad . (610m/305m).
2. Accuracy………………………………………   10 arc sec. (±1/16″ per 100′) (± 1.5 mm per 30m).
3. Self Leveling Range……………………..   ±5°.
4. Slope Matching …………………………..  ±25% Single Axis • 8%.
5. Height Alert…………………………………   Normally active, can be disabled.
6. Rotation Coverage • Speed………….   360° @ 600 rpm or 1200 rpm (selectable).
7. Machine Control Compatible……….  Yes, Including high speed rotation.
8. Warranty…………………………………….  8 Year No Exclusions Warranty.
9. ower source • Life……………………..  Four C- cells @ 200 hours (alkaline).
10. Rechargeable Battery • Life…………  Optional NiMh kit @ 90 hours.
11. Laser Beam Type…………………………  Visible 650nm.
12. Alpha Laser Classification…………  CDRH and IEC Class 2.
13. Dust and Water Sealed………………..   To international standard IP56.
14. Operating Temperature……………….   -4° F to +140° F (-20° C to +60° C).
15. Built to be jobsite tough………………   Unlimited drop height
